CSL1450 10-15mm Dead Bolt Electric Stike

10-15mm Dead Bolt Electric Strike

Purpose

The CSL1450 is ideal where the customer needs electric unlocking of deadlocks, without the worry of handle overrides from the secure side. Fail open versions fitted to fire exit doors, linked into fire alarm systems achieve fire safety with security. Designed to co-operate with deadlocks having a throw of 12-18mm, 10-15mm width and a maximum height of 38mm. Fail locked or fail open on power failure. With the additional feature available of a changeover microswitch, to provide door lock status indication or interlocking facility, for increased security where only one door can be electrically unlocked at a time.

Specifications

• Standard 12v DC operation.
• Designed to suit dead bolt 10-15mm wide x 38mm height with 12-18mm throw.
• 2200lbs Strength.Finish
• Brass body.
• Stainless steel faceplate.Models AvailableCLS1450A – 9421 12v Fail Locked.
  CLS1450B – 9422 12v Fail Locked with microswitch of bolt monitored.
  CLS1450C – 9423 12v Fail Open.
  CLS1450D – 9424 12v Fail Open with microswitch of bolt monitored.
  CSL1450E – 9422/5 12v Fail Locked with dual microswitch of solenoid and bolt monitored.
