CSL0120 Holding Room Screen

Specification

• Door and fixed panels are constructed from 40mm wide steel hollow section framework sheeted both sides with 3mm thick steel skins, mounted within a rolled hollow section frame.
• All glazing is 22.3mm thick toughened laminated glass, the glass retaining frames are only fitted to the corridor side.
• The door is hung from a substantial continuous hinge.
• Fixings to suit a variety of opening constructions.
• The door is supplied as standard with one recessed pull handle on the outside and a Home Office Type 2 heavy duty mortice deadlock.

Finish

• One coat factory applied high build zinc phosphate primer to all mild steel surfaces.

Available Options

• Home Office Type 1 slam action cell lock.
• Bullet resisting glass.
• Intelli-glass privacy glazing.
• Any size / combination of panels can be provided.
• 0.8mm thk rigidised stainless steel bright annealed skin to cell side of door panel. (Pattern ref: 12LG)
• 60 minute Fire Resisting.
